The 24 motor grader delivers high-performance construction and maintenance of mine roads to improve mining truck efficiency. It is equipped with a 24-ft.-wide moldboard and is application matched for medium to large mines running trucks over 200-ton payloads.
- Modular design means components can be removed and installed quicker and easier - up to 70% faster than the 24M in some cases
- Standard Cat GRADE with Cross Slope improves operator productivity and haul road quality
- Optimized weight balance and 15% more low-end torque compared to the 24M
- 11% increase in machine weight provides additional blade downpressure and tractive force to increase blading performance
- Consistent Power-to-the-Ground controls engine power levels to offset cooling fan losses
- 535- to 694-net-hp C27 engine with ACERT technology provides a 15% low-end torque improvement
- 21-in., six-speed planetary, automatic power shift transmission uses the Advanced Electronic Control Strategy (APECS)
- Standard rear view camera and optional front cameras
- Two electrohydraulic joysticks reduce hand and wrist movements by up to 78%
- Touchscreen information display and keypad provide an enhanced operator interface for more efficient control
- Incorporates engine underspeed/overspeed, transmission slip detect, articulation eStop, implements lockout and fluid monitoring
- MineStar ready and comes standard with VIMS and Product Link Elite, which delivers advanced machine operation reporting through VisionLink
