114SD Severe Duty Platform

from Freightliner Trucks - Daimler Trucks North America
Created: September 23, 2011

Freightliner Returns to Mid-BBC Vocationals with 114SD

Freightliner 114SD mixer with BBC of 113 in. and a set-forward front axle position at 31 in.
Freightliner 114SD mixer with BBC of 113 in. and a set-forward front axle position at 31 in.
Clear frame rails behind cab make for easy upfit of mixer equipment.
Clear frame rails behind cab make for easy upfit of mixer equipment.
A range of cylindrical and rectangular aluminum fuel tanks is available.
A range of cylindrical and rectangular aluminum fuel tanks is available.
Bridge-formula bumpers with easily removable tow hooks offer a 29.5-in. front axle position. Steer angle can be 45 degrees.
Bridge-formula bumpers with easily removable tow hooks offer a 29.5-in. front axle position. Steer angle can be 45 degrees.
Air-ride aluminum day cab presents information to the operator in an ergonomic wing dash.
Air-ride aluminum day cab presents information to the operator in an ergonomic wing dash.
114 SD Severe Duty Mixer Platform
114 SD Severe Duty Mixer Platform

1
2
3
4
5
6

The 114SD mid-BBC severe-duty truck has a 114-in. bumper to back of cab (BBC) measurement and a set-forward front axle position at 31 in.

Air-ride, all-aluminum day cab
Up to 45° front wheel cut, depending on equipment
Standard DD13 engine with up to 350 hp and 1,350 lbs.-ft. torque or optional DD13 rated at 450 hp, 1,650 lbs.-ft. torque
Cummins ISC and ISL (1,000 and 1,300 lbs.-ft. torque) available October 2011
Eaton Fuller 10-speed manual transmission
Rear tandem-axle ratings to 58,000 lbs. and optional steer-axle ratings to 22,000 lbs.
