LineWise has released a new self-propelled Tri-Bundle Line Cart designed for use in transmission line construction, maintenance and inspection. The cart is compatible with two- or three-bundle configurations and offers several customizable features to suit specific jobsite requirements.
The unit can be powered by either a rechargeable lithium battery system or a gas-engine-driven hydraulic configuration. The electric option uses two 48V, 30Ah batteries, designed to provide sufficient power for a full workday.
Equipped with non-slip rubber drive wheels, the cart can travel in both directions at speeds up to four miles per hour and handle inclines up to 20 degrees. Joystick controls are positioned for accessibility, and a parking brake is included for added safety. Electric linear actuators articulate the wheels, and the main wheel supports rotate laterally to allow for navigation around yoke plates, insulators and spacers. Center wheels can be raised or lowered for conductor access, and a lower roller adjusts up to 12 inches to accommodate different bundle configurations.
The cart includes a cradle system for placement on conductors by crane or helicopter. The top locking bar, wheels and motors are designed for easy repositioning during setup. Safety tubes are installed across the wheels to help stabilize the cart in the event of wheel misalignment on the conductor.
Additional features include retractable hooks for spacer storage, a non-slip floor, and a folding seat for operator comfort. The cart is built for single-user operation with a total capacity of 600 pounds (272 kg) and is constructed from high-strength aluminum alloy. A bonded work configuration is also available.
