Equipment Trailers July 2007

Product spotlight

1184706191977 10298141

Terex Load King SA70
The 70,000-lb. SA70 hydraulic sliding axle trailer includes a 12,000-lb. line pull winch (20,000-lb. optional) and a 6.5° load angle.

  • 15° dump angle
  • 20 D-Rings and multiple chain slot design
  • Features 80/100 KSI steel, cambered deck beams, crossmembers on 8-in. centers and Apitong decking
  • Hendrickson Turner HT air ride suspension


Trail-Eze T70XT Low Load Angle Trailer
The T70XT low load angle trailer offers a 70,000-lb. distributed and 40,000-lb. concentrated capacity in 10 ft.

  • 48-ft. overall length and 102-in. overall width
  • 12,000-lb. winch and wireless remote control
  • Long tail with 10° load angle and full tilt bed
  • Eight 235/75R X 17.5 radials (H) rating


Trail King Advantage Series SA
The wheels on the Advantage Series Sliding Axle (SA) trailer can move forward 212 in., allowing the deck to tilt down for a 6.5° load angle.

  • Well-suited for loading and unloading equipment with low ground clearance
  • New tapered design of the tail portion of the deck
  • Hydraulic cylinder system eliminates the need for traveling hydraulic lines
  • Flexible track system protects air and electrical lines


Bil-Jax Escalate Hydraulic Lift Trailers
The Escalate hydraulic lift trailers lower and raise the deck to and from the ground.

  • 6° ramp angle
  • ET 7000 with 7,000-lb. capacity
  • ET 12000 with 12,000-lb. capacity
  • Leaf spring suspensions
  • Welded, heavy gauge, powder-coated steel used to create a rugged frame


Featherlite Model 1610
The Model 1610 features Premium Advantage wood flooring with high moisture resistance.

  • Contractor package includes a side door, protective gravel guard, stabilizer jacks, dome light, six recessed tie-downs and e-track on the walls for securing tools and equipment
  • Corrosion-resistant aluminum construction
  • Available in 8- to 18-ft. lengths
  • Optional rear load ramp


JLG Triple-L Trailers
Triple-L trailers feature the Power Deck hydraulic system, which lowers and raises the deck in less than 15 seconds.

  • 20 models in flatbed, utility and fully enclosed configurations
  • 2,000- to 10,000-lb. capacities
  • Deck sizes in 4-ft. 4-in. to 6-ft. widths and up to 16-ft. lengths
  • Two lockable steel compartments
  • Quick-adjust tongue jack
  • 12-volt system powers the hydraulic pump used to lower and raise the deck


Transcraft Lower-deck Height Option
A lower-deck height option of 36 1/2 in. in the unloaded condition is now available on the DTL3000, DTL2100 and D-Eagle drop-deck trailer models.

  • Allows for transport of taller loads, plus provides easier access to the lower deck area
  • Eliminates need to deflate or remove equipment tires to ensure proper legal height of load


Towmaster Contrail C-14LS
The Contrail C-14LS is a deck-over style trailer designed to transport mid-sized equipment and larger skid steers.

  • Hauls 14,000 lbs.
  • Two 7,000-lb. Dexter Torflex axles
  • 235/85R x 16 - 10-ply tires
  • 8' x 16' or 18' deck
  • Wood-covered 5-ft. beavertail and 5-ft.-long, side-adjustable ramps


TerraMarc Load-N-Lift Trailers
The Load-N-Lift hydraulic trailers are suited for a variety of low-clearance, compact and mobile equipment.

  • Completely lower the deck to the ground for ease of loading and unloading
  • Electric hydraulic or manual hand-pump
  • 51- to 81.5-in. widths
  • 10-ft. 10-in., 15-ft. 6-in. and 18-ft. 2-in. lengths


Advance Metalworking Lo Riser Trailer
The 6,000-lb.-capacity Lo Riser trailer features a 74" x 11' 4" load carrying platform that can be hydraulically lowered to ground height.

  • Built-in ramp for drive-on access without any crown point
  • Minimum 5° angle when lowered
  • Constructed of High Strength Low Alloy (HSLA) steel
  • 7,950-lb. GVWR
  • Combination of hydraulic and rubber suspension


Best TB82x16T Tandem Tilt Bed
The TB82x16T tandem tilt bed trailer can be rated up to 16,000-lb. GVWR with a 13,000-lb. capacity and 12° load angle empty.

  • Dampening cylinder for tilt-mode cushioning
  • 7K torsion axles
  • Sealed beam lighting
  • Powder-coated finish
  • Adjustable hitch
  • Eliminates need for ramps


Felling IT Series
The Industrial Tilt (IT) Series offers simplicity of design along with durability.

  • 10° to 14° loading angle, dependent upon deck length
  • True actuating tilt bed
  • 9,980- to 18,000-lb. GVWRs
  • Dual cylinder tilt cushion
  • Deck lengths from 14 to 20 ft.


Landoll 900 Series Traveling Tail Trailer
The 900 Series traveling tail trailer is available in 35- or 50-ton capacities.

  • One hydraulic control for three hydraulic functions
  • No hydraulic lines, hinges or pins behind the tail to maintain
  • Tandem or triple axle
  • 12-, 14- or 15-ft. tail lengths
  • Low load angle to as low as 11° possible with 15-ft. tail
  • Standard powder coat paint, LED lighting package, 12-in. crossmember spacing and more


Eager Beaver Paver PT Series Trailers
The Paver PT Series is designed to safely load rollers, pavers and milling machines.

  • Low front approach
  • Tapered ramps and gradual slope
  • Low load angle
