Spotlight: Material Placing 2006

Miller Spreader MB16P, the LeeBoy LBC-24W, the Toro Cement Bowl attachment and much more.

1140529679603 10305205

Miller Spreader MB16P
The MB16P power buggy offers strength and durability with its 2- by 9-in. solid-steel frame.

  • All six tires filled with SuperFlex gel to eliminate flats
  • Available with poly or steel bucket
  • Recoil or electric-start 13-hp Honda engine

LeeBoy LBC-24W
The LeeBoy LBC-24W concrete curber is designed to give contractors a highly maneuverable, compact curb and gutter machine.

  • Can smoothly pour a radius as tight as 24 in., eliminating most hand forming
  • Guided by a Top-Con System V electronic grade and steering control system for accurate placement
  • Ideal for slipform curb and gutter, alley ribbons and sidewalks up to 4 ft. wide
  • Powered by a 37.5-hp diesel engine

Toro Cement Bowl attachment
The cement bowl attachment for Dingo compact utility loaders allows users to easily haul, mix and pour up to 200 lbs. of dry cement.

  • Enables operator to pour footings without disturbing existing landscape
  • Permits access to areas previously accessible only by hand labor
  • Works in conjunction with high-torque or universal swivel auger power head
  • Powered by loader's auxiliary hydraulic system

Patz Handy Conveyor
The Patz Handy Conveyor moves sand, gravel, broken concrete, wood and more.

  • High capacity
  • Compact and portable

Crown CB16P Series buggy
The CB16P Series buggy is powered by a 13-hp Honda engine.

  • 16-cu.-ft. capacity
  • Cross-link polymer bucket
  • Riding platform locks in upright position for walk-behind applications
  • 6-in. minimum dump height

Miller Formless M-1000
The M-1000 features closed-loop, variable-displacement track, auger and trimmer drive systems.

  • 103-hp John Deere diesel engine
  • Microprocessor controls for elevation and steering
  • Charging hopper with heavy-duty modular auger
  • Standard hydraulic track tensioning system, quick mule mount system and triple grouser track pads
  • Optional auxiliary grade sensor assembly, heavy-duty elevation pump upgrade, urethane or steel track pads and hydraulic side shift

Kenrich Products GP-3A
Kenrich Products offers the GP-3A grout pump, an air-powered version of the company's GP-2HD hand-operated model.

  • Uses an air cylinder and pneumatic logic to create the pumping action
  • Requires only 3 cfm of compressed air at 50 psi
  • Maximum output capacity is 5 gpm
  • Weighs only 27 lbs.

Stone FB1000
The FB1000 Mud Buggy can be configured as a stake bed, flat bed or an extended flat bed.

  • Standard polyethylene mortar tub can be converted in less than 15 minutes
  • Carries up to 10 cu. ft. with a load capacity of 2,500 lbs.
  • 13-hp Honda engine
  • Lockable, fold-up operator platform
  • Extra-large, platform-mounted service brake
  • Dual-action dump pedal

Creative Equipment Design
The Curbcat concrete slip-form curb and gutter attachment turns your skid-steer loader into a slip-form paver ready to pour in minutes.

  • Automatic control of grade and steering using sensors and string line
  • Hydraulic vibrators and cylinders powered by skid-steer hydraulic system
  • Quick, easy hookup and disconnect
  • Molds changeable in minutes
  • Easily transported via pickup or trailer

Ingersoll Rand power buggy
The 16.5-cu.-ft. power buggy from Ingersoll Rand can be used for concrete spreading, demolition debris removal, spot pouring and more.

  • Available with either a steel or poly-type tank
  • 6 in. of bucket clearance in fully dumped position
  • 13-hp. Honda engine
  • Electric or recoil start
  • Optional foam-filled tires to increase stability

Cobra curber
The Cobra Asphalt/Concrete Curber from Salsco, Inc. has nine wheels for stability and a fully enclosed 13-hp Honda engine.

  • 6-in. hard-faced steel auger
  • Mold housing transfers from side to side
  • Variety of standard molds available
  • Oversized hopper compatible with standard wheelbarrow
