Enerpac SCJ_100 Self-Locking Cube

100-ton capacity incremental lifting system has automated mechanical locking for faster and safer lifting.

SCJ100 Cube Jack
SCJ100 Cube Jack

The new Enerpac SCJ-100 model is the latest addition to the Self-Locking Cube Jack product series, offering a compact, 100-ton capacity portable hydraulic solution for incremental lifting and lowering of heavy loads.

  • The Self-Locking Cube Jack uses a base lifting frame and self-aligning, lightweight steel cribbing blocks to provide high-capacity and stable lifting
  • Steel cribbing blocks have several benefits over wood cribbing, including
  • Lightweight steel design, <25kg, can be handled manually
  • Reduce manpower required: Two people do the same work as four people in a quarter of the time
  • Save time: 50% less cycles than climbing jacks
  • Offer a safer and controlled alternative to climbing jacks with wooden cribbing
  • Improve side load
  • Steel cribbing blocks are only inserted once the load is mechanically locked on the cube jack
  • They are easily aligned in a single movement providing optimum safety, so the operator does not need to put hands beneath a load suspended by hydraulic pressure
  • The Cube Jack is derived from the proven Enerpac Jack-Up System, but in a vastly smaller footprint allowing it to be used in confined spaces and without the need for electrical controls
  • The compact size and portability of Self-Locking Cube Jacks offer a powerful solution for numerous applications, such as equipment maintenance, vehicle unloading or jacking a transformer, module, or bridge
  • Up to eighteen 50-lbs (23 kg) steel cribbing blocks can be safely and easily stacked onto the SCJ-100 Cube Jack base frame yielding a maximum height of 118.3 inches (3006 mm)
  • The base frame footprint measures just 25.8 in x 25 in (655mm x 636mm), making it ideal for restricted operating space
  • A low 22 in (558mm) minimum initial jacking height increases flexibility and reduces operational startup time
  • Cube Jacks operate with up to 10,000 psi (700 bar) hydraulic pressure and are compatible with standard pumps, such as the Enerpac Split-Flow Pump that offers the ability to evenly operate multiple Cube Jacks
  • The SCJ-100 Cube Jack comes with a storage frame to make tool maintenance and inventory management easier
