ASV has introduced the next-generation RT-65 Posi-Track loader, now powered by Yanmar. The midsize machine is designed for contractors and owner-operators in landscaping and construction markets.
“We’re committed to providing increasingly durable and high-performing equipment to our customers, and this new RT-65 is a significant addition,” said Peter Ovrebo, product management director — North America, Yanmar Compact Equipment North America. “Not only is the RT-65 now powered by Yanmar — it is redesigned from top to bottom, making it an entirely new model that promises to allow operators an easier and more productive time on the jobsite in virtually every way.”
Power
ASV’s RT-65 is a brand-new radial-lift machine with new hydraulics, engine, controls, wiring, pumps, hoses, frame and more. These components maximize power from the compact track loader’s 67.1-hp Tier 4 Final Yanmar diesel engine and optional 26.7 gpm high flow. The hydraulic system and direct drive pumps transfer more flow and pressure directly to the attachment, resulting in a 2,000-lb. rated operating capacity and 5,714-lb. tipping load. Additionally, the cooling system and hydraulics allow the compact track loader to operate at 100% load, 100% of the time up to 118°F.
The 7,385-lb. RT-65 achieves maximum traction and mobility thanks to ASV’s flagship Posi-Track rubber track undercarriage. It includes a suspension system made up of two independent torsion axles per undercarriage, allowing for traveling speeds up to 9.1 mph. The torsion axles allow the flexible track to maximize contact with the ground, increasing pushing power and lowering ground pressure as low as 4.2 psi. This weight distribution results in performance in steep, wet, muddy and slippery conditions. It also contributes to less risk of damage to sensitive turf.
Performance
The RT-65 offers numerous optional technology features for jobsite performance. The tools can help with repetitive tasks for new and experienced operators.
Auto two-speed provides operators control while grading, in tight spaces or other applications by creating a transition between low- and high-speed modes. Similarly, speed-sensitive ride control improves material retention at higher speeds without the need to switch off the feature when moving to slower-moving applications. Self-leveling features further boost those capabilities. The self-leveling technology automatically levels the load both while raising the machine’s arms and while lowering them.
The RT-65’s work-tool positioner provides the ability to create a button preset for the angle of the attachment based on the application. Return-to-position technology complements that with the ability to set a preset for the height of the loader arms. The two features can be paired or used independently, depending on the task at hand.
ASV
Operator Experience
The RT-65 is a MAX-Series model. Operators can see the attachment and their surroundings with 360-degree visibility. A 7-in. color display provides access to vital monitoring tools, view from the backup camera and integration with service schedules and history. The new RT-65 includes electronic controls. This is complemented by a fully adjustable suspended seat. The machine includes a roof escape hatch.
ASV’s optional Yanmar SmartAssist telematics system changes how operators experience their machine. The service includes features ranging from error detection and notification to real-time operational status updates and daily work reports. Owners can also set theft protection, allowing users to set a range from a specific location and trigger an alert if the machine moves outside of that range.
Serviceability
The machine is accessible, featuring a swing-out radiator, top hood and side doors that provide access to all sides of the engine compartment, including filters and other daily checkpoints. Additionally, the machine’s cooler swings out with the door, allowing access for cleaning.
The RT-65’s Yanmar engine can be serviced from top to bottom at ASV dealers, providing a one-stop-shop experience for maintenance needs.
