D-Series Middleweight Crawler Excavators

Volvo's D-Series middleweight crawler excavators for weight classes between 13 to 25 tonnes include the EC140D, EC160D, EC180D, EC220D and EC235D (EC180D and EC235D available in Europe).

• Volvo Stage IIIB/Tier 4 interim emissions-compliant engines
• ECO mode uses electronic pump control technology to boost fuel efficiency
• Greased and sealed track chains
• Tracks powered by an automatic two-speed shift travel motor
• Multi-disc track brakes
• Work modes include I-idle, F-fine, G-general, H-heavy or (EU only) P-power - machine automatically sets appropriate engine speed for the work mode
• 'Smart' hydraulics system increases total flow and allows improved cycle times by up to 2.5%
• Attachment Management system can store up to 18 presets and enables hydraulic flow to be adjusted as per the requirements of the attachment in use
• Volvo's CareTrack telematic system is standard

EC140D:

• 113 hp at 2,000 r/min max power
• 7,710-lb. max lifting capacity along undercarriage
• 27.4-ft. max digging reach
• 18.2-ft. max digging depth
• 20,950-lb. max breakout force
• Volvo D4H engine

EC160D:

• 141 hp at 2,000 r/min max power
• 11,240-lb. max lifting capacity along undercarriage
• 29.5-ft. max digging reach
• 19.1-ft. max digging depth
• 25,780-lb. max breakout force
• Volvo D4H engine

EC220D:

• 174 hp at 1,800 r/min max power
• 16,420-lb. max lifting capacity along undercarriage
• 32.7-ft. max digging reach
• 22.1-ft. max digging depth
• 32,480-lb. max breakout force
• Volvo D6H engine
