Engines & Components May 2010

Learn more about available gasoline and diesel engines for your fleet.

1274709642547 10293077

QSL9 Engine


The QSL9 8.9-liter engine platform is a fully integrated air-intake to exhaust aftertreatment system that is ready to meet EPA Tier 4 Interim and EU Stage IIIB off-highway emissions.

  • 90% lower Particulate Matter (PM) and 45% lower NOx emissions
  • 240 to 400 hp with maximum torque of 1,200 lb.-ft.
  • XPI Extra-High Pressure Injection fuel system
  • Variable Geometry Turbocharger with a sliding-nozzle design
  • Cooled Exhaust Gas Recirculation system


Cummins Engine Co., Inc.

Tier IV Interim Engines


The Cat C3.4B, C4.4 ACERT and C6.6 ACERT Tier IV Interim/Stage IIIB industrial engines offer ratings from 60 to 174 hp with maximum torque ratings from 310 to 609 lb.-ft.

  • Produce fuel consumption improvements across the entire horsepower band
  • ACERT Technologies achieve a 90% reduction of particulate matter and a 45% reduction of oxides of Nitrogen (NOx)
  • C4.4 ACERT 4.4-liter, four-cylinder platform features a 22% power increase and comes with a single (intercooled) or series turbocharger
  • Available with a range of options suited for compact and mid-range equipment



Interim Tier IV Engines


To meet Interim Tier IV emissions, John Deere Power System engines above 75 hp will couple the Tier III PowerTech Plus engine platform with cooled exhaust gas recirculation (EGR) and exhaust filter technology.

  • 4.5L, 6.8L, 9.0L and 13.5L in-line, four- and six-cylinder models with a four-valve cylinder head, high-pressure fuel system, turbocharging and air-to-air aftercooling system
  • Exhaust filter consists of a diesel oxidation catalyst and diesel particulate filter
  • Optimized package size similar to their Tier III counterparts


John Deere Power Systems

854 Series Tier IV Interim Engines


Perkins Engines completes its Tier IV Interim product range with its 60- to 115-hp 854 Series four-cylinder, 3.4-liter engine.

  • Offer more power and torque from a smaller package
  • Incorporate a common rail fuel injection system, smart waste-gated turbocharger and aftercooler, which are regulated by full authority electronic controls
  • Develop a peak torque of up to 420Nm
  • Available in the 2,200- to 2,500-rpm speed range


Perkins Engines, Inc.

GX and iGX Engines


The GX and iGX series commercial-grade engines offer improvements in power, fuel efficiency, emissions performance and quiet operation.

  • GX240, GX270, GX340 and GX390 overhead valve (OHV) horizontal shaft models
  • iGX340 and iGX390 OHV models with electronic self-tuning regulator (STR) governor
  • 6% power increase via an advanced combustion chamber design, Digital Capacitive Discharge Ignition and increased compression ratio


American Honda Motor Co.

Tier III/Tier IV Interim Engines


DEUTZ offers a full line of engines rated from 30 to 700 hp and designed to meet stringent EPA Tier III/Tier IV emission standards.

  • 67- to 114-hp TCD 2010 L4 four-cylinder models offer a 3.6-liter displacement
  • TCD 2011 series available with integrated cooling system or conventional external cooling system
  • TCD 2012 series liquid-cooled, in-line four- and six-cylinder models range from 91 to 252 hp at 2,300 to 2,400 rpm and include turbocharging with charge air cooler, externally cooled EGR and Diesel Particulate Filtration


Deutz Corporation

Vanguard Single-Cylinder Engines


Four Vanguard single-cylinder engines offer gross power ratings from 5.5 to 10.0 hp.

  • Incorporate the TransportGuard System, an integrated switch that simultaneously shuts off the ignition and fuel for transport
  • Feature a high-mounted canister-style air cleaner, all-metal fuel tank mounted directly to the engine block, heat-treated PTO bearing races and commercial-style carburetor
  • Forged crankshaft with dual ball bearings minimizes friction and heat buildup


Briggs & Stratton Corporation

LCT Engines and Parts for Small Construction Equipment


LCT air cooled, single-cylinder, horizontal shaft engines are available in 6 (208cc), 10 (291cc) and 12 hp (414cc) with manual and electric start options.

  • Applications include concrete trowels, floor saws, pressure sprayers, vibratory plate compactors, water pumps and other small construction equipment
  • LCT replacement engine parts include internal engine parts, air filters, carburetors, fuel and ignition parts, mufflers, starter parts and more


Stens Corporation

EX40 OHC Engine


The EX40 air-cooled, four-cycle engine delivers a maximum output of 14 hp and utilizes chain-driven overhead cam (OHC) technology.

  • Meets CARB and EPA Tier III emission standards
  • Automatic decompression timing system reduces pulling force 30% to 40%
  • Applications include general construction equipment, power generators, compressors and more


Subaru Robin

V-ACT Tier IV Interim Engines


The V-ACT (Volvo-Advanced Combustion Technology) Tier IV Interim engine systems will adopt a combination of in-cylinder and external solutions to meet the emissions reductions targets.

  • Feature ultra-high-pressure, variable fuel injection systems, cooled exhaust gas recirculation (EGR) and precise control of the turbochargers
  • EMS engine management systems provide enhanced engine monitoring and control
  • Integrated exhaust aftertreatment system reduces particulate matter by 90%


Volvo Construction Equipment
