Ultrasonic Detection On-screen Display

Brigade’s ultrasonic proximity sensors minimize both vehicle damage and collisions with pedestrians, cyclists or objects.

Brigade Hd

Working in conjunction with a camera monitor system and up to two ultrasonic detection systems, the on-screen display module warns the driver of obstacles close to the vehicle by overlaying 3-stage audible and visual ultrasonic data onto the camera image on the vehicle’s monitor.

  • Compatible with Sidescan, Frontscan and Backscan and Brigade camera monitor systems
  • UDS overlay will appear on a black background if no cameras installed
  • Graphics can be overlaid left or right on the monitor
  • Audible warning via monitor
  • Ultrasonic system fault displayed on monitor
  • Compatible with MDR
  • Operating temperature: 22 to +158°F
  • Power consumption:1.7 Watts
  • Current: 140mA
  • IP30; CE marked; EMC approved: E; FCC Approved; IC Approved
