PK 200002 L-SH Knuckle Boom Crane

Palfinger Pk 200002 L Sh Knuck 11307583
Palfinger Logo 10944678

Palfinger's PK 200002 L-SH crane features a long boom design for operations requiring high outreach and an exclusive boom profile system (P-Profile) that makes the boom lighter, stiffer and stronger.

  • Mount on standard truck chassis
  • High working speed thanks to double circuit control
  • Special stabilizer concept with extendable rear stabilizer ram
  • Maximum precision and safety due to AOS
  • Maximum utilization of the working range thanks to extended HPSC
  • More efficiency with fly-jib due to DPS Plus
  • Additional applications with Power Link Plus
  • Maximum lifting moment: 1,090,030 ft.-lbs.
  • Maximum lifting capacity: 88,200 lbs.
  • Maximum hydraulic outreach: 83 ft. 12 in.
  • Maximum outreach with fly jib: 157 ft. 3 in.
  • Maximum operating pressure: 5,583 psi
  • Pump capacity: 2 x 31.7 gal./min.
  • Slewing torque with one gear: 90,390 ft.-lbs.
  • CONEXPO-CON/AGG Booth #3311 Silver Lot

Brochure: Palfinger PK 200002 L-SH Knuckle Boom Crane
