Portable Pumps

Latest in Portable Pumps and accessories for March 2005.

1123525082149 10306382

Grindex Bravo Pump Series

The Bravo slurry pump series is designed for very abrasive applications.

  • Hydraulic components constructed of Ni-Hard 4
  • Models deliver between 470 and 2,000 gpm
  • Capable of handling slurry and other fluids with high concentrations of sand and stones
  • Godwin Dri-Prime and Sub-Prime Pumps

    The Dri-Prime and Sub-Prime pumps can be used for general dewatering applications.

  • Dri-Prime automatic self-priming models achieve maximum flows to 10,000 gpm, heads to 600 ft. and solids handling to 5 in. in diameter
  • Sub-Prime electric submersible pumps available in 1/2 to 90 hp with flows to 5,000 gpm, heads to 375 ft. and solids handling to 3.2 in. in diameter
  • 6-hp GSP60SL and 4-hp GSP40SL SlimLine electric submersibles have a maximum diameter of 7.25 in.
  • Tsurumi LB-480 and LB-480A

    The 2/3-hp LB-480 and LB-480A electric submersible pumps have a 2-in. discharge bore.

  • 110V/6.1A
  • 39.5-ft. shutoff head
  • 62.4-gpm maximum flow
  • Multiquip QP Series Trash Pumps

    The QP Series 2- and 3-in. trash pumps feature eight models with maximum flows up to 396 gpm.

  • Dual-discharge ports
  • 98-ft. heads
  • Engine options include Honda, Robin, Hatz and Yanmar
  • Incorporate 1 1/2-in.-diameter fill and drain ports with plastic plugs to avoid casing damage
  • Honda WB Series Pumps

    Honda pumps feature heavy-duty full-frame protection, a rigid-mounted cast iron pump volute and an abrasive-resistant, silicone-carbide mechanical seal.

  • WB20 and WB30 powered by 4.5- and 5.5-hp Honda overhead valve engines with Oil Alert
  • WB30 delivers a maximum discharge capacity of 275 gpm and a maximum head of 83 ft.
  • ITT Flygt Ready 8S Pump

    The 33-lb. Ready 8S submersible trash pump is constructed of wear- and corrosion-resistant, stainless steel and synthetic materials.

  • Features a 2-in. NPSM discharge and handles solids up to 1 1/2 in. in size
  • Achieves 36 ft. of head and pumps up to 110 gpm
  • 1.1-hp motor powered by single-phase 115- or 230-volt power
  • Built-in overload protection
  • Abrasion-resistant silicon carbide seal faces
  • BJM SPV Series

    The SPV Series portable electric submersible pumps feature a patented lip seal at the rotor shaft bore combined with an O-ring for double protection of the shields.

  • Model SPV48 pumps 475 gpm in high volume and 365 gpm in high head configuration with heads up to 115 ft.
  • Models SPV160 and SPV160H pump 1,000 gpm at 30-ft. head and 300 gpm at 100-ft. head with maximum heads of 260 ft.
  • Thompson Piston Wellpoint Pumps

  • These diesel-powered piston wellpoint pumps are available in 3- and 6-in. models equipped with a self-priming, positive-displacement piston pump.
  • Silent Knight sound-attenuated enclosure reduces noise level below 64 dB(A) at 23 ft.
  • Capable of operating up to 11 days using 4 gal. of fuel per day
  • Double-sealing piston rod prevents oil from entering the environment
  • Gorman-Rupp Pump Line

    Gorman-Rupp offers a large variety of pumps, including standard centrifugal and self-priming centrifugal trash pumps, submersibles, diaphragm pumps and silent series models.

  • Sizes range from 1 to 2 in. with ratings from 10 to 8,500 gpm
  • 5- to 550-ft. TDH
  • Handle up to 3-in. spherical solids
  • Power options include electric motor, gas or diesel engine, closed-coupled, flex-coupled or direct drive
  • Manufactured from a variety of steels, iron, aluminum and other materials
