The new- generation ZX-135/70 includes the mini XChassis axle design, which extends and retracts the axles to and from the stowed position with a footprint of 8' 2" x 13' 6" retracted or 12' 11" x 13' 6" extended.
- Load sense cell technology monitors the weight in the platform and disables drive, steer and certain boom functions if the load exceeds the platform load limit
- Hydraulically driven generator options include a 7.5- or 12-kW welder-ready package or 3-kW AC generator
- Simple two-point calibration process to set up the primary boom, secondary boom and jib bell crank in as little as 15 minutes
- Provides a 135-ft. maximum platform height, 69 ft. 9 in. of horizontal outreach, 75 ft. of up-and-over clearance and 600-lb. platform capacity
- Telescoping Jib-Extend jib extends from 12 ft. (retracted) to 20 ft. and includes 360˚ continuous rotation turntable, 160˚ platform rotation and 110˚ vertical range of motion
- Four-wheel drive with full-time positive traction plus four-wheel steer with front wheel, rear wheel, crab and coordinated steer options
- Intuitive control system provides menu-based adjustments for machine and component calibration, as well as on-screen multi-language system diagnostics
- Platform controls feature toggle switches and a tactile membrane surface and proportional Hall-effect joysticks for all major functions
