2803ZT Compact Excavator
The 2803ZT zero tailswing compact excavator features a longer undercarriage, a sturdy track width and an optional counterweight for added stability.
- Weighs up to 5,886 lbs. with canopy
- 9-ft. maximum digging depth with 5,778 lbs. of bucket digging force
- Side-mounted, 20-hp Yanmar three-cylinder, water-cooled, Tier III diesel engine
- Rear-mounted hydraulic and fuel tanks for easy access to all maintenance points
- Features a spacious cab with a low height, two driving speeds, pilot-operated pedals and an X-shaped chassis frame constructed of high-strength steel
Mustang Mfg. Co., Inc.
283Z Compact Excavator
The 2.8-ton 283Z features zero tailswing maneuverability, which allows the machine's superstructure to rotate entirely within the tracks.
- Operator compartment size maximized by mounting the 20.4-hp Yanmar diesel engine on the side and hydraulic and fuel tanks on the rear
- Cab versions come standard with heater/defroster, interior light, windshield wiper, windshield washer system and the ability to open the windows
- Narrow track width of 11.8 in. and low ground pressure of 3.8 psi
- Can be transported on a passenger car trailer with a permissible weight of 3.5 tons
- Optional 250-lb. rear weight further increases stability with no tail projection
Gehl Company
28Z3
The 2.8-metric ton 28Z3 zero tailswing compact track excavator provides optimal visibility and performance in confined working areas.
- 20.4-hp Yanmar three-cylinder engine
- 9-ft. maximum digging depth
- Available with standard or long dipperstick
- Cab or canopy work station with an ergonomically designed operating environment
- Includes rubber tracks, dozer blades, boom-mounted working lights and a control pattern selection switch
- Lightweight and compact enough to be hauled with a standard size pickup trailer
Wacker Neuson Corporation
35VX Compact Excavator
Weighing in at 7,500 lbs., the 35VX features over 17 ft. of reach, a digging depth of 11 ft. 4 in. and bucket breakout force of 7,668 lbs.
- 27.6-hp water-cooled diesel engine
- Standard expandable undercarriage extends from 5 ft. to 5 ft. 11 in.
- Zero tailswing design with 360° rotation and an independent swing boom allows work in confined spaces and around walls or obstacles
- Auxiliary hydraulic piping accommodates one- and two-way hydraulic attachments
IHI/Compact Excavator Sales
E60 and E80 Excavators
The 13,556-lb. E60 and 18,689-lb. E80 excavators feature increased service intervals, operator comfort and durability.
- Service interval for greasing bushings extended to 250 hours
- Spacious cab with an operator seat that adjusts nine ways and a heating and air conditioning system with true automotive-style controls
- 50- and 57-hp Interim Tier IV-compliant engines with auto-idle and electronic engine rpm control system
- 13-ft. 7-in. and 15-ft. 6-in. dig depths
- Pin-coupler attachment system standard on the E60 and optional on the E80
- In-track boom swing allows work in constricted conditions
U17 Compact Excavator Line
The U17 zero tailswing compact excavator provides increased hydraulic flow for fast, responsive operation and heightened traction force for tough backfilling jobs.
- More than 3,000 lbs. of bucket breakout force
- 7-ft. 7-in. maximum digging depth
- 17-hp Kubota D902-E3 Tier IV-compliant engine
- 11.9-gpm hydraulic pump capacity
- 3-ft 3-in. overall width
- Hydraulic, expandable variable width tracks
Kubota Tractor Corp.
ViO55-5B Mini Excavator
The ViO55-5B mini-excavator features a zero tail swing design that allows for 360-degree turning of the counterweight within the width of the crawler.
- 6-ft. 6-in. total track width
- 9,015-lb. maximum bucket digging force
- 13-ft. 8-in. digging depth
- ViO crawler technology by Advanced Stability
- 39.5-hp Yanmar TVN series C&S (Clean and Silent) diesel engine
- Tailor-made hydraulic quick coupler standard
- Angle blade option
Yanmar America Corp.
