SSV75
ENGINE
Model V3307-CR-TE4Emission certification Tier 4Engine gross power HP (kW) 74.3 (55.4)/ 2600Displacement 203.3 (3331)Cylinders 4Bore and stroke 3.8 (94) Ã 4.8 (120)Aspiration Turbocharged
LOADER SPECIFICATIONS
Tipping Load. 50% 2690 (1220)Tipping Load. straight 5380 (2440)Breakout forceBucket; lbf. (kgf) 5884 (2669)Lift arm lbf. (kgf) 4850 (2200)Lift arm path Vertical
UNDERCARRIAGE
Standard tire sizeNone 12-16.5-10PRChain size ASA#None 100Maximum traveling speedLow mph (km/h) 7.4 (11.9)High mph (km/h) 11.8 (19.0)Maximum traction force 8494 (3853)Ground clearance in. (mm) 8.1 (207)
HYDRAULIC SYSTEM
Auxiliary hydraulic flow gpm (l/min.) 20.9 (79.0)Auxiliary hydraulic pressure psi (kgf/cm2) 3271 (230)StandardAuxiliary hydraulic flow gpm ( l/min.) 20.9 (79.0)High rangeAuxiliary hydraulic flow gpm ( l/min.) 30.4 (115.0)
SERVICE REFILL CAPACITIES
Hydraulic tank gal. (l) 4.2 (16.0)Fuel tank capacity gal. (l) 26.9 (102.0)OPERATING WEIGHT (INCLUDE OPERATOR WEIGHT 175LBS.)None 8157 (3700) / 8422 (3820)
