XL Low-profile Hydraulic Detachable Gooseneck Trailer

XL Specialized Trailers releases hydraulic detachable gooseneck trailer

Xl Low Profile Hdg Trailer 2019 Final (1)

The Low-Profile Hydraulic Detachable Gooseneck (HDG) trailer has a loaded deck height of only 15 in. and 4.5-in. ground clearance to accommodate loads that may otherwise require a dropside trailer.

  • Capacity of 110,000 lbs. in 12 ft.
  • 13-ft. gooseneck with a swing clearance of 110 in. and a relief cut-out that provides added space between the truck and trailer
  • Hydraulic neck detaches and re-attaches quickly using a power unit or a wet kit
  • Three-beam deck design offers an improved strength-to-weight ratio
  • Enhanced main deck features a bucket well in the rear and a toolbox at the front for storage space
  • Numerous tie-down points with seven pairs of bent d-rings along the outer beams, 12 chain drops per side on the outer rails and four chain drops around the toolbox
  • Swing-out outriggers on 24-in. centers
  • Wheel area’s drop bolster height of 37 in. allows for machinery to be loaded on the rear
  • Third axle airlift can lift up when not needed
  • Notched-out tail channel allows easy access to controls at the rear, and the air control valve is conveniently located in the bolster
  • Frame prepped for a flip axle to allow a fourth axle when necessary
