Excavator Equipment January 2008

Excavator Equipment

1203023833162 10303140

Kubota KX080-3

  • 4,660 lbs. of bucket force and 8,554 lbs. of arm crowd force
  • 64-hp, direct-injection diesel engine with auto-idling system
  • Automatic downshifting
  • Three-pump, load-sensing hydraulic system

Volvo ECR88

  • 56.8-hp engine
  • Weighs 18,078 lbs.
  • Digging depth of 13 ft., 7 in.
  • Digging force bucket 12,589 lbs.
  • Tail Swing Radius of 47.6 in.

Hitachi Zaxis 17U-2

  • Adjustable-width tracks and a backfill blade with foldable end sections that reduce the overall width from more than 50 to 40 in.
  • 14.8-hp engine, 4,173-lb. operating weight and a 7-ft. 1-in. maximum digging depth
  • Standard quick coupler/hydraulic attachment package

Terex TC50

  • 39.4-hp Yanmar 4TNV88 engine
  • Load-sensing and load-independent flow division hydraulics system matched to the machine’s size
  • Maximum dig depth of 12 ft. 1 in.
  • Maximum reach of 20 ft. 4 in.
  • 2.5- to 13.2-cu.-ft. bucket capacities

Hyundai R35Z-7

  • Maximum bucket digging force of 7,059 lbs.
  • 10.33-ft. maximum digging depth and 11.35-ft. dumping height
  • 27.5-bhp Yanmar engine
  • Offset boom
  • Modern three-stage hydraulic pump
  • Two travel speeds


  • 8-ft. 4-in. minimum front swing
  • 12-ft. 10-in. digging depth with a 21-ft. 4-in. reach
  • 55-hp Yanmar diesel engine
  • 1.7/3.3-mph travel speeds
  • Auxiliary hydraulics

Yanmar Mini Excavators

  • True zero tail swing models in 6,300- and 7,000-lb. class
  • Universal boom design is 1.5 times thicker than before and increased breakout forces with new dig depths of 9 ft. 6 in. and 11 ft. 4 in.
  • PTO switch mounted on wrist control
  • Hydraulic quick coupler and VICTAS stability control add to productivity

Kobelco SR-3 Series

  • 27SR-3, 30SR-3, 35SR-3 and 50SR-3 incorporate a zero tailswing design with center boom swing
  • 5,490- to 10,384-lb. models rated from 21.3 to 40.8 net hp
  • Maximum digging depths from 8 ft. 4 in. to 11 ft. 9 in.
  • Standard auxiliary hydraulics and pattern control changer
  • One pump dedicated to boom swing circuit for simultaneous boom, arm or bucket operation without affecting swing operation
  • Optional steel tracks

New Holland Mid-size Excavators

  • Zero tailswing E70 and short-radius E80 weigh 16,400 and 17,600 lbs. and deliver 54 net hp
  • 15-ft. 3-in. maximum digging depths
  • 11,903-lb. bucket breakout forces
  • Single- and bi-directional auxiliary hydraulics

Bobcat 425 ZTS

  • Maximum digging depth of 8 ft. 4 in. and a maximum reach of 14 ft. 10 in. at ground level
  • 5,058-lb. bucket breakout force (5,530 lbs. with long arm)
  • 26-hp liquid-cooled diesel engine
  • Two-speed travel motors provide a 1.2-mph low and 2.3-mph high travel speed

Gehl 383Z ZTS

  • Weighs 7,826 lbs. with canopy
  • Longer undercarriage
  • Auto-2-Speed drive motor load-sensing system automatically shifts between low and high range

John Deere 17D

  • Adjustable-width tracks and a backfill blade with foldable end sections
  • Tracks extend to a 50-in. width
  • 7-ft. 9-in. maximum digging depth and 13-ft. 5-in. digging reach
  • Multi-function operations
  • Standard mechanical quick coupler/hydraulic attachment package

Takeuchi TB138FR

  • Side-to-side (STS) offset boom
  • Control pattern selector valve for SAE or ISO patterns
  • Available with open canopy or fully enclosed cab
  • Tilt-up operator’s platform and full-opening engine compartment
  • Automatic fuel bleed system

Mustang Compact Excavator Line

  • 10 models that provide a broad range of available options
  • Zero and short tailswing designs
  • Boom systems consist of one piece of steel rather than two pieces welded together for a system that is less susceptible to wear

Case B Series

  • Range from 5,666 to 10,383 lbs. and incorporate 21.3- to 40.8-net-hp Tier II engines
  • Maximum dig depths from 9 ft. 2 in. to 11 ft. 9 in. with up to 7,936 lbs. of bucket digging force
  • Zero tailswing and center-swing boom

Compact Power Boxer BX-10

  • Delivers 1,764 lbs. of ripping force with the standard 9-in. bucket
  • 13-hp Honda engine
  • 35.5-in.-wide dedicated track system
  • 6-ft. 6-in. maximum digging depth

JCB 8080 ZTS

  • 13-ft. 10-in. dig depth and a bucket breakout force of 11,240 lbf.
  • Boom offset at an angle
  • 57.6-hp Tier II-compliant, liquid-cooled diesel engine
